5.0 inch TFT LCD MODULE CT050BPL07
- View full size
Products Category
| Size: | 5.0 inch TFT LCD MODULE |
| Part No.: | CT050BPL07 |
| Resolution: | 800 (RGB) x 480 |
| Viewing Angle: | 12 O'clock |
| Module size(mm): | 120.90(W) x 75.95 (H) x 3.0(T) |
| Active Area(mm): | 108.00(W) x 64.80(H) |
| Display Type: | Normally White, Transmissive 40PIN |
| Driving IC: | / |
| Interface: | 24 bits RGB Interface |
| Backlight: | LED backlight |
| Brightness (cd/m2) | 350 |
| Contrast Ratio: | 600 |
| Touch Panel: | Optional with resistive and capacitive touch |
