10.1 inch TFT LCD MODULE CT101BQU11
- View full size
Products Category
| Size: | 10.1 inch TFT LCD MODULE |
| Part No.: | CT101BQU11 |
| Resolution: | 1024(RGB) x 600 |
| Viewing Angle: | 12 O'clock |
| Module size(mm): | 235.0(W) x 143.0 (H) x 2.8(T) |
| Active Area(mm): | 222.72(W) x 125.28(H) |
| Display Type: | Normally White,Transmissive 40PIN |
| Driving IC: | / |
| Interface: | LVDS |
| Backlight: | LED backlight |
| Brightness (cd/m2) | 220 |
| Contrast Ratio: | 500 |
| Touch Panel: | Optional with resistive and capacitive touch |
